Woodward EGCP-1 User Manual

EGCP-1 Engine Generator Control Package Manual 26059
138 Woodward
MAX STOP TIME Min: 1
Max: 1200
60 seconds
Item: Range: Default: As Set Value: Note:
NEXT GENSET
DLY
Min: 1
Max: 1200
30 seconds
REACTIVE LOAD CONTROL MENU
Item: Range: Default: As Set Value: Note:
VARPF MODE Disabled
PF control
VAR
PF control
Item: Range: Default: As Set Value: Note:
VARPF GAIN Min: .01
Max: 20.0
3.0
Item: Range: Default: As Set Value: Note:
VOLTS RAMP
TIME
Min: 0.0
Max: 1000.0
30
Item: Range: Default: As Set Value: Note:
VARPF SHAR
GAIN
Min: .01
Max: 20.0
1.0
Item: Range: Default: As Set Value: Note:
VARPF
STABILITY
Min: 0.0
Max:20.0
1.0
Item: Range: Default: As Set Value: Note:
KVAR
REFERENCE
Min: 0.0
Max: 30000.0
10.0 kVAR + = generate
- = absorb
Item: Range: Default: As Set Value: Note:
PF REFERENCE Min: -0.5 =.5 LEAD
Max: +.5 =.5 LAG
0.0= 1.00 LAG 0.0 = UNITY PF
+ = LAG
- = LEAD
Item: Range: Default: As Set Value: Note:
PF DEADBAND Min: 0.0
Max: 1.0
0.0 PF
PROCESS CONTROL MENU
Item: Range: Default: As Set Value: Note:
PROCESS GAIN Min: 0.001
Max: 100.0
0.1
Item: Range: Default: As Set Value: Note:
PROCESS
STABILITY
Min: 0.0
Max: 20.0
1.0
Item: Range: Default: As Set Value: Note:
PROCESS
DERIVATIVE
Min: 0.0
Max: 20.0
0.1
Item: Range: Default: As Set Value: Note:
