Manual 26059 EGCP-1 Engine Generator Control Package
Woodward 1
Chapter 1
General Information
Introduction
This manual describes the Woodward EGPC-1 Engine Generator Control
Package, models 8406-020 (12 Vdc) and 8406-021 (24 Vdc).
Declaration of Incorporation
In accordance with the EMC Directive 89/336/EEC and its amendments, this
controlling device, manufactured by the Woodward Governor Company, is
applied solely as a component to be incorporated into an engine prime mover
system. Woodward Governor declares that this controlling device complies with
the requirements of EN50081-2 and EN50082-2 when put into service per the
installation and operating instructions outlined in the product manual.
NOTICE:
This controlling device is intended to be put into service only upon
incorporation into an engine prime mover system that itself has met the
requirements of the above Directive and bears the CE mark.
Control Options
The EGPC-1 control requires the following power supply input voltages, with 6
watts as the nominal power consumption at rated voltage:
•
9–15 Vdc (12 Vdc nominal)
•
18–32 Vdc (24 Vdc nominal)
Control Part Numbers
Part Number
12 Vdc
Supply Voltage
24 Vdc
Supply Voltage
Nominal PT
Input Voltage
Range
Nominal CT
Input Current
Range
8406-020 X 90–277 Vac rms 0–5 A rms
8406-021 X 90–277 Vac rms 0–5 A rms
Nominal AC Voltage as measured across + to – inputs for AC Mains/Bus and
Generator
PT sensing.
