Woodward SEG HighPROTEC MRA4 User Manual

Smart View
Setting up the Connection PC - Device
Set-up a Connection via Ethernet - TCP/IP
Establishing a connection via TCP/IP to the device is only possible if your
device is equipped with an Ethernet Interface (RJ45).
Contact your IT administrator in order to establish the network connection.
Part 1: Set the TCP/IP Parameters at the panel (Device)
Call up the menu »Device parameter/TCP/IP« at the HMI (panel) and set the following parameters:
• TCP/IP address
• Subnetmask
• Gateway
Part 2: Setting the IP address within Smart view
• Call up the menu Settings/Device Connection within Smart view.
• Set radio button Network Connection.
• Enter the IP-Address of the device that should be connected.
Page 68 EN MRA4 04/09

Woodward SEG HighPROTEC MRA4 Specifications

General

Device Type	Protection Relay
Application	Generator protection
Mounting	DIN Rail
Communication	RS-485
Input Voltage Range	24-250 V DC
Protection Functions	Overcurrent, overvoltage, undervoltage, frequency
