Worcester 50/70

4
Fig. 2. General Assembly.
Control Box Assembly
Manual reset over-
heat thermostat
phial
Automatic reset high
limit thermostat phial
Burner locking
screw
Burner seal
gasket
Side panel
locking screw (A)
Burner
Optional pump
location
Manual reset
overheat
thermostat
Strain relief
bush
Burner plug-in
connector
High limit thermostat
Fire valve clip
Side panel
Top panel
Front panel
Thermostat
knob
Control thermostat
phial
Phial retaining
plug
Split pin
