Fig. 2. Conventional Flue Appliance. (CF/LLD)
Manual air
vent
Electrical
top cover
Manual reset
overheat
thermostat
System
pressure
gauge
Side
panel
Side panel locking
screw (A)
Burner seal
gasket
Burner locking
screw
Pressure
relief valve
Central heating
flow
Pump
Burner
Front
panel
Expansion
vessel
Electrical
panel
User operating switch
(Optional programmer
position)
Top panel
Thermostat
knob
Fire valve
clip
Manual reset over-
heat thermostat
phial
Automatic reset high
limit thermostat phial
Control thermostat
phial
Split pin
Control Box Assembly
