Service Clearances
Greenstar Ri
ErP
- 6 720 813 340 (2014/09)
5 Service Clearances
Your installer will have provided adequate space around the boiler for safety and servicing access.
Fig. 6 Service clearances
[*] Minimum clearances to removable door
[**] Minimum clearances required for servicing
[***] Height for either 60/100 flue or 80/125 flue above the boiler
CAUTION: Restricted space.
The boiler may overheat.
▶ Do not restrict this space with the addition of cupboards, shelves etc. next to the boiler.
6720813340-05.1Wo
5
m
m
5
m
m
6
0
0
mm
*
*
2
0
mm
*
