WORKHORSE CUSTOM CHASSIS
Service Manual
W SeriesWCC
SECTION
6.2
PAGE
78
Engine Mechanical
W Series Chassis
TOC
© 2006 WorkhorseCustom Chassis — All Rights Reserved
Oil Level Sensor
13 N·m 115 lb in
Oil Pan Baffl e Bolts
12 N·m 106 lb in
Oil Pan Closeout Cover Bolt - Left Side
12 N·m 106 lb in
Oil Pan Closeout Cover Bolt - Right Side
12 N·m 106 lb in
Oil Pan Cover Bolts
12 N·m 106 lb in
Oil Pan Drain Plug
25 N·m 18 lb ft
Oil Pan M6 Bolts - Oil Pan-to-Rear Housing
12 N·m 106 lb in
Oil Pan M8 Bolts - Oil Pan-to-Engine Block and Oil Pan-to-Front Cover
25 N·m 18 lb ft
Oil Pan Skid Plate Bolt
20 N·m 15 lb ft
Oil Pressure Sensor
35 N·m 26 lb ft
Oil Pump Cover Bolts
12 N·m 106 lb in
Oil Pump Relief Valve Plug
12 N·m 106 lb in
Oil Pump Screen Nuts
25 N·m 18 lb ft
Oil Pump Screen-to-Oil Pump Bolt
12 N·m 106 lb in
Oil Pump-to-Engine Block Bolts
25 N·m 18 lb ft
Positive Battery Cable Clip Bolt
9 N·m 80 lb in
Power Steering Pump Bolt - RPO HP2
25 N·m 18 lb ft
Power Steering Pump Bracket Bolt - RPO HP2
25 N·m 18 lb ft
Power Steering Pump Harness Bolt - RPO HP2
25 N·m 18 lb ft
Power Steering Pump Harness Ground Bolt - RPO HP2
25 N·m 18 lb ft
Power Steering Pump Rear Bolt
50 N·m 37 lb ft
Rear Oil Seal Housing Bolts
30 N·m 22 lb ft
Spark Plugs
15 N·m 11 lb ft
Starter/Generator Control Module (SGCM) Cover Bolts - RPO HP2
9 N·m 80 lb in
Stator Stud - RPO HP2
16 N·m 12 lb ft
Throttle Body Nuts
10 N·m 89 lb in
Throttle Body Studs
6 N·m 53 lb in
Torque Converter Bolt - 4L60-E/4L65-E Transmissions
63 N·m 47 lb ft
Torque Converter Bolt - 4L80-E/4L85-E Transmissions
60 N·m 44 lb ft
Transmission Bolt/Stud
50 N·m 37 lb ft
