Setting the cutting depth
We recommend picking a cutting depth that exceeds the material thickness by about
3 mm. A deeper cutting depth leads to a cleaner cut.
To set the cutting depth, proceed as follows:
1. Loosen the cutting depth adjustment lever
26
and select the desired cutting
depth using the marks on the cutting depth scale
25
(see figure B).
2. Re-tighten the cutting depth adjustment lever.
Using the laser guide
Only turn the laser beam on when the saw is resting on the workpiece.
CAUTION!
Risk of injury!
Use of the laser guide other than as described in this instruction man-
ual can cause eye injury.
To use the laser guide, proceed as follows:
1. Place the saw on the workpiece.
2. Press the laser guide on/off switch
2
.
Turning the saw on and off
The saw is equipped with an electronic soft start system and starts after a short
delay.
To turn the saw ON, proceed as follows:
1. Plug the saw into the mains.
2. Press and hold the on/off safety switch
24
.
3. At the same time press the on/off switch
1
and keep it pressed until the saw
starts.
4. Release the on/off safety switch.
To turn the saw OFF, proceed as follows:
1. Let go of the on/off switch
1
.
