Preparation and assembly
Before you use the saw, prepare it and any accessories as described in the following
chapters.
Checking the circular hand saw and package contents
1. Take the saw out of the packaging and check whether the saw or the individual
parts exhibit damages. Also make sure that all contents have been received (see
figures A and C). If there are any damages or missing parts, do not use the saw.
Contact the manufacturer via the service address indicated on the warranty card.
Inserting and replacing the batteries
NOTICE!
Make sure that the laser guide on/off switch
2
is not pressed while
changing the batteries.
To insert or replace the batteries, proceed as follows:
1. Using a Phillips-head screwdriver, loosen the screw and remove the battery com-
partment cover
3
(see figure A).
2. Remove any existing dead batteries and dispose of them in an environmentally
friendly way.
3. Insert 2 new alkaline batteries (LR 44). Pay attention to the polarity (+/-) as shown
on the bottom of the battery compartment.
4. Replace the battery cover and secure it with the screw.
Removing and fitting a saw blade
NOTICE!
Risk of damage
The rotational direction arrows on the saw blade must coincide with
the rotational direction arrows on the saw blade guard
10
and the
protective cover
13
.
