3. Parts description
1. Spindle lock button
2. Auxiliary handle position x 3
3. On/o switch
4. Main handle
5. Battery release button*
6. Battery pack*
7. Auxiliary handle
8. Pin wrench
9. Grinding disc x 5
10. Wheel guard for grinding
11. Outer ange
12. Inner ange
13. Carry case
* Battery not included. Shown only for instructional purposes.
