12
COMPONENT LISTS
1. CARVING BIT
2. CHUCK
3. COLLET
4. SPINDLE LOCK BUTTON
5. SPANNER
Not all the accessories illustrated or described are included in standard
delivery.
TECHNICAL DATA
Type Designation WX739 WX739.X (739-designation of machinery,
representative of rotary tool)
WX739 WX739.X*
Voltage
20 V Max
**
Motor type Brushless
Collet size 3.2 mm
Rated capacity 38 mm
Spindle thread M7
Rated speed 5000-35000 rpm
Machine weight (bare tool) 145 g
* X=1-99, A-Z, M1-M9 there are only used for different customers, there are no safe
relevant changes between these models.
** Voltage measured without workload. Initial battery voltage reaches maximum of
20 volts. Nominal voltage is 18 volts.
NOISE INFORMATION
A weighted sound pressure L
pA
: 70.3 dB(A)
A weighted sound power L
wA
: 81.3 dB(A)
K
pA
&K
wA
3 dB(A)
Wear ear protection.
