TO MANUALLY FEED THE LINE (See Fig L)
If required line can be feed out manually.
To operate, press and release manual line feed
button (16), while gently pulling out the lines
until the lines reach the line cutter.
If the line extends past the line cutter, too much
line has been fed out.
If too much line is fed out, remove the spool
cap and turn spool counter-clockwise until the
line is at the desired length.
TO REMOVE THE CAP
Press and hold in the two latches (12) (See Fig
M).
Pull cap away from the spool holder.
When retting the spool cap,
keep all areas of the cap and spool holder
clean.
Replace the cap, pressing rmly down towards
the spool holder to ensure cap is fully located.
Check that the cap is correctly fitted by trying to
remove it without depressing the two latches.
TO REPLACE CUT LINE.
For your convenience it is recommended you
buy spool and line complete.
To fit spool and line complete:
Remove old spool.
Place new spool into cap with cut out areas of
the spool in line with eyelets.
Release line from cleat and feed line through
eyelet .
Refit the cap.
To fit nylon line only:
WARNING! Take approximately 10ft(3m)
of line. Insert 5/8”(15mm )of line into the
spool holes and wind line in the direction of the
arrows on the top of the spool.
Your Trimmer is designed to use only line with
a maximum diameter of 0.065”
IMPORTANT: Leave approximately 4”(100mm)
of line unwound and place into cleat.
Care should be taken to ensure that the line is
neatly coiled on the spool. Failure to do so will
impair the efficiency of the automatic line feed.
Then fit spool as described in “To fit spool
and line complete”.
STORING YOUR GRASS
TRIMMER
A) ASSEMBLY THE WALL MOUNT
BRACKET (WG150.1 WG150.2 WG150.3)
Before you attach the wall-mount bracket to
the wall, make sure to check the charger cable
length to the wall socket. Attach the wall-
mount bracket to the wall with the five screws
provided.
Tighten all five screws securely. Carefully check
the bracket after mounting to make sure that no
movement can occur during use. (see fig N.1).
WARNING: Always make sure your
wall-mount bracket is securely
mounted to the wall. Failure to do so could
result in an accident, resulting in possible
serious personal injury.
B) CHARGER AND BRACKET MOUNTING
(WG150.1 WG150.2 WG150.3)
To attach the charger onto the wall-mount
bracket, insert the charger legs into the slots in
the bracket and push the charger towards the
left, making sure the legs are fully insert into
the slots.(See N.2)
To remove the charger from the bracket, press
the release button and push the charger out
of the slots.(See P). Be careful not to trap your
finger.
C) STORING YOUR GRASS TRIMMER
(WG150.1 WG150.2 WG150.3)
Adjust the auxiliary handle near to main handle
and insert it to the bracket , then the grass
trimmer can be stored into the wall mount
bracket as illustrated (See O.1)
D) WALL-MOUNT CHARGING (WG150.1
WG150.2 WG150.3)
The charger can be attached in the wall-mount
brackets. The battery pack can be charged inside
the wall-mount bracket. (See O.2)
Store in a dry place where your trimmer
can be protected from damage.
