6. ADJUSTMENT OF THE TELESCOPIC
SHAFT (See G)
Unscrew the lower locking knob (4) in the
direction indicated to unlock.
Adjust the length of the telescopic shaft to the
most comfortable length.
Tighten the lower locking knob.
7. MAIN HANDLE ROTATION (See Fig H)
Unscrew the upper locking knob (3) in the
direction indicated to unlock.
Adjust the angle of the main handle to be
clockwise 90 degree max.
Turn the upper locking knob in the opposite
direction to lock.
8. ADJUSTMENT OF AUXILIARY HANDLE
Pull up the auxiliary handle locking lever (5).
Hold the lever and rotate the auxiliary handle
to the most comfortable and balanced position
(See Fig I)
Release the lever, your auxiliary handle has been
locked.
9. ADJUSTMENT OF THE TRIMMER HEAD
ANGLE TO THE SHAFT
Use both of your hands, one grips the shaft,
another on the head, then apply adequate
force to adjust the trimmer head to the most
comfortable position. The ratchet mechanism
will make a heavy clicking sound which is
normal and not a defect (See Fig J).
OPERATION
WARNING:
Always wear the eye
protection.
Never lean over the trimmer
head. Rocks or debris can ricochet or be thrown
into eyes and face and cause blindness or other
serious injury when opening unit, check for the
following:
Wear eye protection and heavy clothing. Hold
front handle with one hand and auxiliary
handle with the other hand. Keep unit below
waist level. Work only from your right to your
left to ensure debris is thrown away from you.
Without bending over, keep line near and
parallel to the ground (perpendicular when
edging) and not crowded into material being
cut.
WARNING: Make sure that line is fed
out before operation. Make sure motor
is up to full speed before trimming.
WARNING: Use only 0.065”(1.65mm)
diameter line. Other sizes of line will not
feed properly and will result in improper cutting
head function or can cause serious injury. Do
not use other material such as wire, string,
rope, etc. Wire can break off during cutting and
become a dangerous missile that can cause
serious injury.
Trimming
Hold the bottom of the trimmer head about
3.25”(8 cm) above the ground and at an angle.
Allow only the tip of line to make contact. Do
not force trimmer line into work area.
Edging (See Fig K)
Unscrew the upper locking knob (3) and rotate
the main and auxiliary handle to 90º with
cutting head (See Fig K).
Retighten the upper locking knob.
Adjust trimmer head angle to be the lowest
horizontal setting. Then position the wheel on
the ground for edge mode. The guard has two
white line guides to indicate the cutting line
position. Align these marks with the edge of
your lawn.
While edging allow the tip of the line to make
contact. Do not force the line. The rotation
wheel helps protect the unit and keeps the unit
from contacting the ground. Take extra caution
while edging as objects can be thrown from
the trimmer line.
AUTOMATIC LINE FEED SYSTEM
When initially switching on the trimmer, a small
length of line is fed out.
A ‘clattering’ noise will be heard when the line
hits the line cutter. DO NOT BE ALARMED this
is quit normal. After about 5 seconds the line
will be cut to the correct length and the noise
will reduce as the motor achieves full speed.
If the noise of the line being cut can’t be heard,
more line will be fed out.
To feed more line, it is rst necessary to allow
the trimmer to stop completely, then restart,
allowing the motor to reach full speed.
Repeat above 4 until you hear the lines hitting
against the line cutter. (Do not repeat this
procedure more than 6 times)
