3-in-1 Cordless Lawn Mower
EN
1. SWITCH LEVER
2. CABLE CLIP
3. GRASS BAG FILLING INDICATOR
4. GRASS COLLECTION BAG
5. SAFETY KEY
6. UPPER HANDLE
7. LOCK CAM LEVER
8. LOWER HANDLE
9. SAFETY FLAP
10. BATTERY PACK*
11. MOTOR COVER
12. CHARGER*(See Fig A2)
13. MULCH PLUG (See Fig H)
14. BLADE BOLT (See Fig P1)
15. BLADE (See Fig P1)
16. CHARGED INDICATOR LIGHT (GREEN) (See Fig.A3)
17. CHARGING INDICATOR LIGHT (RED) (See Fig.A3)
18. INTELLICUT DIAL
* Not all the accessories illustrated or described are included in standard delivery.
