OPERATING INSTRUCTIONS
Note: Before using the tool, read the instruction book carefully.
INTENDED USE:
This tool is intended for the fastening and loosening of bolts, nuts and various threaded fasteners. This
tool is not intended for use as a drill.
ASSEMBLY AND OPERATION
Action Figure
Before operation
Checking the battery charge condiction See Fig. A1
Removing The Battery Pack See Fig. A2
Charging The Battery See Fig. A3
Installing The Battery Pack See Fig. A4
Assembly
Inserting and Removing Bits and Socket See Fig. B1, B2
Assembling the belt hook and bit clip See Fig. C1, C2, C3, C4
Operaton
Switch Lock See Fig. D1
Forward And Reverse Rotation Control
Warning: Never Change The Direction Of Rotation When The
Chuck Is Rotating, Wait Until It Has Stopped!
See Fig. D2, D3
Variable Speed Control
See Fig. E
Operating the On/Off Switch
Warning: Do not operate for long periods at low speed because
excess heat will be produced internally.
See Fig. F
Using The Sight Light
Before operation, the LED light will be activated when the On/Off switch
is slightly depressed, and will automatically turn off 20 seconds after the
On/Off switch is released.
The tool and battery are equipped with a protection system. When the
LED Light is quickly flashing 3 seconds and turn off, the system will
automatically cut off power to the tool to extend battery life. The tool will
automatically stop during operation if the tool and/or battery are placed
under one of the following conditions:
• Overloaded: The tool is operated in a manner that causes it to draw
an abnormally high current. In this situation, release the Trigger Switch
on the tool and stop the application that caused the tool to become
overloaded. Then pull the Trigger Switch again to restart.
• Overheated: Under the condition above, if the tool does not start, the
Tool and Battery are overheated. In this situation, let the Tool and Battery
cool before pulling the Trigger Switch again.
• Low battery voltage: The remaining Battery capacity is too low and the
tool will not operate. In this situation, remove and recharge the Battery.
Warning: To turn on the light, press the On/Off switch and make sure
the Forward/Reverse Rotation Control is on right/left position.
See Fig. F
