20V Multi-Function Inflator EN
9
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
This product is a multifunctional device, combining
inflators, tire pressure monitor, lighting, SOS
warning four functions in one.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Checking the Battery Pack
Condition
NOTE: Fig. A1 only applies for
the battery pack with battery
indicator light.
See Fig .A1
Removing the Battery Pack See Fig. A2
Charging the Battery Pack
See Fig.
A3,A4
Installing the Battery Pack See Fig. A5
OPERATION
Power button
Press the button to turn on the
tool and hold the button to turn
it off.
NOTE: To avoid unintentional
start up, the power button
will automatically shut down
when the Start/Stop button
is not pressed for a certain
period after the power
button is turned on.
See Fig. B
Changing the unit of
measure
Press INCREASE PSI and
DECREASE PSI simultaneously
to change the unit of measure
See Fig. C
Setting the pressure
Press INCREASE PSI or
DECREASE PSI to set the
pressure value.
NOTE: Object’s original air
pressure will be displayed once
connected. Without connection,
“0” will be displayed.
See Fig. D
Inflating
Connect the object to the tool.
Then press Start/Stop button.
Once it reaches the set pressure,
the tool will automatically stop.
NOTE: Make sure all
connections have been
tightened before inflating.
NOTE: In E2, loosen the locking
nut on the valve stem first.
WARNING: When inflating
the floating tube, check the
status of the tube rather than
using the pressure value on the
gauge.
See Fig.
E1,E2,E3, E4
Work Light
Press the work light button to
cycle through work light or SOS
emergency light.
WARNING: Do not look
towards the light directly.
See Fig. F
Storing adapter and hose
See Fig.
G1,G2
Battery protection system
The tool is equipped with a battery protection
system. The system will automatically cut off
power to the tool to extend battery life. The tool will
automatically stop during operation if the battery is
placed under one of the following conditions:
• Overloaded: The tool is operated in a manner
that causes it to draw an abnormally high current.
In this situation, turn the tool off and stop the
application that caused the tool to become
overloaded. Then turn the tool on to restart.
• Low battery voltage: The remaining Battery
capacity is too low and the tool will not operate.
In this situation, remove and recharge the Battery.
MAINTENANCE
Remove the battery pack from the tool
before carrying out any adjustment,
servicing or maintenance.
Your power tool requires no additional lubrication or
maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free
of dust. Occasionally you may see sparks through
the ventilation slots. This is normal and will not
damage your power tool.
