1. FINE-ADJUSTMENT KNOB FOR DEPTH-OF-CUT
2. SCALE FOR FINE ADJUSTMENT OF DEPTH-OF-CUT
3. CLAMPING LEVER
4. LEFT HANDLE
5. SCALE FOR COARSE ADJUSTMENT OF DEPTH-OF-CUT
6. DEPTH STOP
7. WING SCREW FOR DEPTH STOP
8. DUST BOOTS
9. STEP BUFFER
10. BASE PLATE
11. GUIDE PLATE
12. LOCKING SCREW FOR GUIDE ROD
13. TIGHTENING NUT WITH COLLET
14. SPINDLE LOCK BUTTON
15. RIGHT HANDLE (WITH ON/OFF SWITCH)
16. LOCK-ON BUTTON/LOCK-OFF BUTTON
17. THUMB-WHEEL FOR SPEED PRE-SELECTION
18. ON/OFF SWITCH
19. SPANNER
20. DUST ADAPTER
21. PARALLEL GUIDE (See Fig. F)
22. CENTRING PIN (See Fig. H)
23. MARKINGS FOR ZERO-RESET (See Fig. C)
24. GUIDE BUSHING (See Fig. D)
25. SCREWS AND NUTS (See Fig. B)
26. INDEX MARK
27. GUIDE RODS (See Fig. H)
28. WING KNOBS (See Fig. H)
29. ROUTER BIT*
30. ROLLER GUIDE( See Fig. J)
* Not all the accessories illustrated or described are included in standard delivery.
