OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction
book carefully.
INTENDED USE
The power tool is intended for driving in and loosening
screws as well as for drilling in wood, metal and plastic.
Action Figure
Before operation
Charging the Battery
NOTE:
1. Maximize Battery Performance
Prior to initial use, the battery must
be charged 5 hours to fully utilize the
battery capacity.
2. When the battery is full charged, the
light turns green.
See Fig. A
Assembly and adjustment
Inserting and Removing the Bit
Cartridge
See Fig. B, C
Assembling and Removing the Screw
Holder
See Fig. D1,
D2
Forward/reverse/lock
WARNING: Never change the
direction of rotation when the
chuck is rotating, wait until it is
stopped!
See Fig. E1,
E2, E2
Operation
Selecting a Bit See Fig. F1, F2
Drilling a Pilot Hole See Fig. G
Assembling screw See Fig. H1,
H2, H3
Tightening and Loosening Screw See Fig. I1, I2
Operating the On/Off Switch
WARNING: Do not operate for
long periods at low speed
because excess heat will be produced
internally.
See Fig. J
LED Light Indicator See Fig. J
Automatic Spindle Locking
NOTE: When the slide driver is out of
power, this function enables the cus-
tomer tightening or loosening screws
manually.
MAINTENANCE
Your power tool requires no additional lubrication or
maintenance. There is no user serviceable parts in your
power tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free of
dust. If you see some sparks flashing in the ventilation
slots, this is normal and will not damage your power tool.
