Worx WX255.1 User Manual

9
1. SLIDE COVER
2. FORWARD/REVERSE ROTATION CONTROL
3. SOFT GRIP HANDLE
4. CHARGING INDICATOR
5. CHARGING SOCKET
6. ON/OFF SWITCH
7. LED LIGHT
8. SCREW HOLDER
9. CHUCK
10. BIT CARTRIDGE
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WX255.1 (250~269-designation of machinery, representative of Battery-powered Screwdriver)
Charger input
100-240V~50/60Hz 190mA
Charger output 4.2V
500mA
Rated voltage 4V
Max*
Charger input power 3W
Battery capacity 1.5Ah (li-Ion)
No load speed 230/min
Maximum torque 3N.m
Machine weight 0.5kg
Charger protection class
/II
Charging time 5 hours (Approx.)

Worx WX255.1 Specifications

General

Brand	Worx
Model	WX255.1
Category	Power Screwdriver
Language	English
