use. To switch off your tool just depress and
release the on/off switch.
7. AUXILIARY HANDLE
Slide the handle onto the drill and rotate to
the desired working position. To clamp the
auxiliary handle rotates the handle clockwise.
To loosen the auxiliary handle rotate the
handle anti-clockwise (See Fig. E).
WARNING: Always use the auxiliary
handle.
8. FORWARD AND REVERSE ROTATION
CONTROL
With the drill pointing away from you, push
the forward/reverse-lever (3) to the left
“ “for forward rotation. Push the forward/
reverse-lever (3) to the right for reverse
rotation “ “.
WARNING: Never change the
direction of rotation while the tool
is rotating, wait until it has stopped.
9. ADJUSTABLE DEPTH STOP
Fit the drill bit into the chuck. Loosen the depth
stop by rotating the handle anti-clockwise.
Slide the depth stop until the distance
between the depth stop end and the drill bit
end is equal to the depth of hole/screw you
wish to make. Then clamp the depth stop by
rotating the handle clockwise.
10. FUNCTION MODE SELECTION (See Fig. F)
The operation of the gearbox for each
application is set with the function mode
selection switch (4), To change between
functions, depress the unlocking button
(15) and rotate the selector to the desired
operating mode.
For simultaneous drilling and impacting of
concrete or masonry, choose the Hammer
drilling position.
For screw driving, drilling into steel, wood and
plastics choose the Rotary drilling position.
For impacting only - for light chipping,
chiseling and demolition applications choose
the Hammer position.
WARNING: The operating mode
selector switch may be actuated
only at a standstill.
WARNING: Prolonged use will cause
the aluminum housing to become
hot, do not touch.
WORKING HINTS FOR
YOUR DRILL (HAMMER)
If your power tool becomes over heated, set
the speed to maximum and run no load for 2-3
minutes to cool the motor. SDS-plus tungsten
carbide drill bits should always be used for
concrete and masonry. When drilling in metal,
only use HSS drill bits in good condition.
Always use a magnetic bit holder when using
short screwdriver bits. Where possible use a
pilot hole before drilling a large diameter hole.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional
lubrication or maintenance. There are no user
serviceable parts in your power tool. Never
use water or chemical cleaners to clean your
power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place.
Keep the motor ventilation slots clean. Keep
all working controls free of dust.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order to
avoid a hazard.
ENVIRONMENTAL
PROTECTION
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or retailer for
recycling advice.
