Cordless rotary hammer
WX382 WX382.1
WX382.2 WX382.3 WX382.4
10
B1
A
OPERATING INSTRUcTIONS
NOTE: Before using the tool, read the instruction
book carefully.
INTENDED USE
The machine is intended for hammer drilling in
concrete, brick and stone. It is also suitable for drilling
without impact in wood, metal, ceramic and plastic.
Machines with electronic control and right/left rotation
are also suitable for screwdriving.
BEFORE PUTTING INTO OPERATION
A) CHARGING THE BATTERY PACK
The battery pack charger supplied is matched to the Li-
Ion battery installed in the machine. Do not use another
battery charger.
The Li-Ion battery pack is protected against deep
discharging. When the battery pack is empty, the
machine is switched off by means of a protective circuit:
The chuck no longer rotates.
In a warm environment or after heavy use, the
battery pack may become too hot to permit charging.
Allow time for the battery pack to cool down before
recharging.
When the battery pack is charged for the first time and
after prolonged storage. The battery pack will accept a
100% charge after several charge and discharge cycles.
B) TO REMOVE OR INSTALL BATTERY PACK
(See Fig. A)
Depress the battery pack release button to release and
slide the battery pack out from your tool. After recharge,
slide it back into your tool. A simple push and slight
pressure will be sufficient.
OPERATION
1. INSERTING AND REMOVING DRILL BITS &
ADAPTORS (11, 13) IN THE SDS CHUCK
Take care that the dust protection cap (1) is not
damaged when changing tools.
— INSERTING (See Fig. B1, B2)
Clean and lightly oil the bit before inserting. Insert the
dust-free bit into the bit holder with a twisting motion
until it latches.
The bit locks itself. Check the locking by pulling on the
tool.
B2
