Worx WX390 Safety And Operating Manual

D2
1
2
C2
SDS-plus
D4
B
F
A1
2
1
H
I
19
E
A2
C1
SDS-plus
2
1
RoundHex
D1
19
G
1
2
RoundHex
D3
1. DUST PROTECTION CAP
2. TOOL HOLDER LOCKING SLEEVE
3. FORWARD AND REVERSE ROTATION CONTROL
4. ONOFF SWITCH
5. BATTERY PACK
6. HAMMER DRILL DRILL SELECTOR DIAL
7. BATTERY PACK RELEASE CLIP
8. LED LIGHT
9. SDS KEYLESS CHUCK ADAPTOR
10. PH2 SCREWDRIVER BIT
11. HSS METAL DRILL BIT 5mm,6mm)*
12. SDS PLUS DRILL BITS 6mm,8mm)*
* Not all the accessories illustrated or described are included in standard delivery.

Worx WX390 Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Motor type	Brushed motor
Product color	Black, Orange
Power source	Battery
Impact rate	5000 bpm
Rated speed (max)	900 RPM
Rated speed (min)	0 RPM
Impact energy (max)	1.2 J
Drilling diameter in steel (max)	10 mm
Drilling diameter in concrete (max)	13 mm

Weight and Dimensions

Depth	68 mm
Width	259 mm
Height	184 mm
Weight	1250 g
