Worx WX392 - Operation

Cordless Rotary Hammer EN
11
the exposure level over the total working period.
Helping to minimise your vibration and noise
exposure risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration and noise accessories.
Plan your work schedule to spread any high
vibration tool use across a number of days.
ACCESSORIES
WX392 WX392.9 WX392.2
Battery charger
1
(WA3880)
/
1
(WA3880)
Battery pack
(WA3553)
2/1
SDS drill bits
3 (8mm, 10mm,
12mm)
/
Kit of SDS bits
& chisel point
/1
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for hammer drilling and
chiseling in concrete, brick and stone. It can be used
for chiseling in concrete and tile in different required
angle, without other tool. It is also suitable for drilling
without impact in wood, metal, ceramic and plastic.
OPERATION
ACTION FIGURE
Inserting drill bit / chisel See Fig. A1
Removing drill bit / chisel See Fig. A2
Adjusting the auxiliary handle See Fig. B
Adjusting the depth gauge See Fig. C
Checking the battery charge condition
NOTE: Fig. D1 only applies for the
battery pack with battery indicator light.
See Fig. D1
Charging the battery pack
NOTE:
• The battery is shipped uncharged.
It must be fully charged before the
first use.
• More details can be found in
charger’s manual.
See Fig. D2
Inserting or removing the battery pack
See Fig.
E1, E2
Forward and reverse rotation control
WARNING: Never change the
direction of rotation when
the chuck is rotating, wait until it
has stopped!
See Fig.
F1, F2
Switch lock
Note: The switch trigger can be
locked in the off (center) position.
See Fig. F3
On/off switch with variable speed
control
See Fig. G
Selecting the function mode
More details refer to FUNCTION
SELECTION
WARNING: The function
selector dial may be actuated only
at a standstill.
WARNING: Prolonged use will
cause the aluminum housing to
become hot, do not touch.
See Fig. H
Drilling (SDS Keyless chuck adaptor
– not supplied)***
See Fig. I
Impact drilling See Fig. J
Chiseling See Fig. K
Bit rotation (only use it for chiseling)
NOTE: Turn the locking sleeve round
by hand to choose an appropriate
bit angle for chiseling, then rotate
the function selector dial to select
chiseling
symbol. Now you can
start chiseling with the required angle
by this machine.
See Fig. L1
Chiseling with an required bit angle See Fig. L2
Temperature dependent overload
protection
/
Protection against deep discharging /
***NOTE: The SDS keyless chuck adaptor illustrated
or described in operation table or figures is not
included in WX392 delivery. It is sold separately.
