SERVICE WORK ON THE CHASSIS 8
11
8.1 Raising the motorcycle with a lift stand
Note
Danger of damage The parked vehicle can roll away or fall over.
– Park the vehicle on a firm and level surface.
401942-01
– Raise the motorcycle in accordance with the instructions of
the vehicle manufacturer.
Neither wheel is in contact with the ground.
– Secure the motorcycle against falling over.
8.2 Removing standard fork legs
H03150-10
– Remove the standard fork legs as per the instructions of the
vehicle manufacturer.
8.3 Installing the WP PRO COMPONENTS fork legs
M01743-10
– Install the fork legs in accordance with the instructions of the
vehicle manufacturer.
Bleeder screws
1
are positioned toward the front.
The second milled groove (from the top) is flush with the
upper edge of the upper triple clamp.
