Wren Kitchens 150 Pull Out - Parts View; Hardware View; Assembly Guide

BASE UNIT
150 - 300 Pull Out
Assembly Guide
For Internal Use: FI.WR.INS.029_WKIN00101_BASE_PullOut_150-300_1Dr_Rev4.indd
Page 1
(F) x8
Wooden Dowel
(G) x8
Cam Dowel
(Expanding)
(H) x8
Cam Lock
(K) x6
30mm
Screw
(L) x20
15mm
Screw
(N) x1
Door
Buer
(J) x6
16mm
Runner
Screw
(X) x8
19mm
Screw
(M) x4
Cover
Cap
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
Panel A
x1Back Panel
Panel C
x2 Base Fixed Panel
Legs
x4
Frontal
(Packed separately)
x1
Panel B
x2 End Panel
REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
L Bracket
x2
