Wright Manufacturing Stander T - Operators Area and Controls

18
4.1 Operator’s Area
1 - Anti-Tip Wheels
2 - Brake Handle
3 - Deck Lift Handle
4 - Dash/Control Panel
5 - Fuel Tank
6 - Upright Pad
7 - Battery Box
8 - Foot Platform
4.2 Model & Serial Location
 The plate is affixed to the left side frame below the battery stand.
 Stated on the plate will be the model, date of assembly and serial number, these will be needed when
ordering parts.
8
3
2
1
4
7
6
5
