Wright Manufacturing Stander T - Deck Lift and Safety Systems

20
2
1
4.6 Deck Lift Lever
The “Quick Cut” height selector has fifteen different settings, ranging from 1.5” – 5.0” and will adjust the cut
height in ¼” increments. To operate, insert detent pin (1) in desired cut height hole, grab deck lift handle and
press the top button down (2) with thumb and lower to the selected cut height. The deck handle has a locking
mechanism when the button is released but it is also recommended to use the detent pin as well.
4.7 Safety Interlock System
The Wright Stander Intensity is equipped with a safety interlock system. The PTO must be disengaged, brake
applied and control levers in the neutral position in order to start the machine. With the brake applied, the
controls are locked in the neutral position.
Brake “On” Brake “Off”
