Revision 1.0 - 12/08/2013 22
Dash Layout - Right Hand Side Console
34. Kneeling Switch.
Keeping the lower part of the switch depressed
lowers the vehicle to its lowest position
(kneeling). Kneeling stops when the switch is
released. Briefly depressing the upper part of
the switch returns the vehicle to normal position.
Note:- To prevent injury please ensure that the
area beneath the boarding step is clear before
lowering the vehicle.
35
36
35. Battery Isolator Switch.
This switch disconnects the
electrical system from the batteries.
It must be switched on for the
electrical equipment to operate.
36. Foot Switch Right.
This switch activates the microphone for
the bus to base radio system, allowing
the driver to keep in contact with base.
23
24
25
26
27
29
28
30
3133
32
34
23
24
25
26
27
29
28
30
3133
32
34
Optional
To Next Page
