Revision 1.0 - 12/08/2013 49
Vehicle Filler locations
The hydraulic steering reservoir is located
behind a hinged panel on the O/S front of
the vehicle.
The hydraulic oil level is
correct when the top
of
the internal
reservoir filter is just submerged
in oil.
Ensure that the filler cap is replaced
securely.
See fluid and lubricants section of this
manual for correct oil type.
See Environmental Warnings
Warning
Engine Oil and Dipstick
Engine Oil
The engine oil filler is located on the rear
offside corner of the vehicle. Check the oil
level using the dipstick. Fill with engine oil
as required. Ensure that the filler cap is
replaced securely.
Always use the correct grade of oil, and
take care not to over fill allowing time for
the
engine oil to reach the engine and settle.
Engine Oil Specification - Euro 5
15W - 40 ACEA E5 API CI-4
Hydraulic Oil - Steering
