3 Wear-Plate/Wear-Ring Replacement Procedure
Warning
Extreme caution is needed when working in the hopper and waterbox. Use lock-out tag-out procedures. Al-
ways remove the ignition key and put it in your pocket or other secure place when working in the hopper and
water-box.
Note: The Western Shotcrete Equipment Warrior Shotcrete Pump, frame no.109 and higher are equipped
with an automatic accumulator discharging system* that will discharge the accumulator if the ignition key-
switch is in the off position or if the electrical system loses power. NOT if the engine stalls. (i.e. Engine runs
out of fuel, etc.) The operator should not rely solely on this system: he or she shall use the following precau
-
tionary procedure:
f) With the engine shut down, turn the ignition key-switch to the on position.
g) Turn the pump switch to the on position.
h) Repeatedly switch the swingtube from reverse to forward until the swingtube no longer shifts.
i) Toggle the pump switch to the off position.
j) Turn the key-switch to the off position.
Note: The electrical system must work properly for this procedure to work.
1 Remove key from engine ignition.
2 Remove Remixer paddle-shaft.
3 Remove 5” Outlet flange. (85150)
4 Remove cotter key and 1 3/8” nut (85511) from S-tube shaft.
5 Slip off the Spacer cap. (85512)
6 Remove Bell-crank assembly (85500) by loosening the two 3/8” locking bolts then removing the two 1”
bolts, also the 3/4” clevis bolt.
7 Slip off the Bronze spacer. (85513)
8 Examine both the 3/4” id bushing (85503) in the Bell-crank and the 3/4” clevis bolt (85522) for wear.
Replace if necessary.
9 Remove Outlet Housing. (85171) If you have difficulty removing the housing use Western Shotcrete Equip
-
ment’s housing puller tool. (87104)
10 Slide the S-tube back through the opening in the rear of the hopper.
11 Remove the hardened outlet (85320) by removing the six 3/8” bolts.
12 Wrap a shop towel around the threaded end of the S-tube shaft.
13 Carefully remove the S-tube valve (85300) by rotating it upside down and letting the shaft go into one of
the material cylinders. (Do not scratch the chrome finish on the inside of the material cylinder) then you will
be able to lift the S-tube valve out of the hopper. The S-tube valve weighs about 135 lbs., so care must be
used to remove it. Do not try to lift it out by yourself. Two people can remove it with care.
* See Hydraulic System sec. 2.4 Accumulator
