Wulftec / M.J. Maillis Group
Page 16 of 36
Version 1.7.1 /November 2014
Wrapper Controls - Options (Cont’d)
Pictogram Controls
Functions
*Top platen off/on When at ON, the top platen will be active when the
machine is set to operation. When at OFF, the wrap
sequence will be performed without activating the top
platen.
*Top platen
up/down
With the machine in manual mode, this switch allows
the top platen to be moved up or down.
*Clamp jog Opens or closes the clamp jaws. There is a four (4)
second delay before the clamp jaws close to allow the
operator enough time to place film in jaws. The carriage
will not feed the film if the clamp jaws are closed.
*Reset Brings the carriage down and moves the rotary arm
back to home position.
*Cut arm
Off/on
Used to activate or deactivate the cut arm.
*Auto/manual mode Used to select the automatic or the manual mode.
When in automatic mode, all automatic options will be
active. When in manual mode, all manual options will
be active.
*Cradle forward Moves the cradle rollers forward to a desired position.
*Cradle speed Used to set the speed of the cradle rollers .
