GB - 10
Technical specifications
ISS 45-M automatic
Item no. -- 0701 146 X
Mains voltage V 220-240
Frequency Hz 1~ 50/60
Max. performance W 1380
Rated power W 1200
Container capacity l 43
Filling quantity (liquid) l 30
Air volume (max.) m
3
/h 140
Negative pressure (max.) kPa (mbar) 22,0 (220)
Power connection data of the power tools W 100-2200
Surface of the flat fold filter m
2
0,6
Type of protection -- IPX4
Protective class -- I
Suction hose connection (nominal width) mm 35
Length x width x height mm 520 x 380 x 695
Typical operating weight kg 13,7
Ambient temperature °C -10...+40
Relative air humidity % 30-90
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 67
Uncertainty K
pA
dB(A) 1
Hand-arm vibration value m/s
2
<2,5
Uncertainty K m/s
2
0,2
Power cord H07RN-F 3x1,5 mm
2
Item no. Cable length
EU 0707 138 116 7.5 m
26
