Tool Specifications
Compressor K 200 K 280 K 400
Article number 701 220 701 228 701 240
Intake air quantity 200 l/min 284 l/min 366 l/min
Effective delivery quantity 115 l/min 152 l/min 180 l/min
Rated input 1.1 KW 2.2 kW 2.2 kW
No-load speed 2850 rpm 2850 rpm 2850 rpm
Oil quantity 0.1 l 0.35 l 0.44 l
Oil type ISO 100 ISO 100 ISO 100
Rated voltage 230 V 230 V 230 V
Insulation class F F F
Safety class / II / II / II
Maximum pressure 8 bar 10 bar 10 bar
Reservoir content 9.5 l 20 l 50 l
Cylinder bore 47 mm 55 mm 47 mm
Stroke 37 mm 42 mm 37 mm
Fuse protection 8 A 10 A 16 A
Ambient temperature +5 - +40 °C +5 - +40 °C +5 - +40 °C
Length/width/height 410/340/630 mm 480/410/800 mm 880/350/700 mm
Weight approx. 21 kg 33 kg 46 kg
For Your Safety
Working safely with this machine
is possible only when the operating
and safety information are read
completely and the instructions
contained therein are strictly follo-
wed.
Before each use of the machine,
check the cable and plug. If dam-
age is detected, do not use the ma-
chine. Have repairs performed only
by a qualified technician. Never
open the machine yourself.
❏ Compressors should only be operated and serv-
iced by trained personnel.
❏ The operator of this machine is responsible for
observing the valid instructions, and in particu-
lar for adhering to the scheduled testing times
for the compressed air reservoir and the regula-
tions for the prevention of accidents (VGB 16).
❏ The safety valve 13 has been secured against
becoming altered. The blow-off pressure pre-set
by the manufacturer must not be changed.
❏ No changes may be made on the machine by
the customer, in particular, the compressed air
reservoir 16.
❏ Caution! Danger of burning! When the plant is
in operation, the unit and pressure tube 2 be-
come hot.
❏ Do not place any inflammable objects in the vi-
cinity of the compressor.
❏ Keep children and animals away from the op-
erating area and thereby prevent any injuries
being caused by equipment connected to the
compressor.
❏ Do not operate the compressor without an air
filter.
❏ Do not move the compressor if the reservoir is
under pressure.
❏ Before commencing any work on the machine,
pull out the mains plug and ensure that the plant
is depressurised.
❏ Use only original Würth parts and accessories.
GB
☞
For further notes on safety refer to enclosed Sheet
