18
Spraying system
Nozzle
Model: SNZ-14000A
Number of nozzles: 4
Trend: rotary atomizing nozzle
Length of spray rod: 1,010mm
Atomizing size: 90-550μm (according to operation
requirements)
Effective spray width: 2-5m (depending on operating
height and consumption per ha)
Peristaltic pump
Model: PP-14A
Quantity: 4
Trend: peristaltic pump
Flow rate: 1.4L/minute (single pump)
5.6L/minute (4 pumps)
Smart liquid container
Model: LT-2010A
Capacity: 16L
Error range: ±0.2%-3.4%
Material: plastic (HDPE)
Obstacle collision avoidance system
XCope
Model: XCOPE201819
Power consumption: 19W
Operating frequency: 30Hz
Obstacle avoidance direction: avoid obstacles in front
Obstacle avoidance direction: according to the flight
Obstacle avoidance direction: direction
Obstacle sensing range: 1.5-20m
Viewing angle: ±30° (horizontal)
Viewing angle: 0.2m below and 0.3m above the
Viewing angle: obstacle avoidance system (vertical).
Viewing angle: Safe distance: 2.5m (the distance
Viewing angle: between propeller tip and the obstacle
Viewing angle: after the aircraft brakes stably) Service
Viewing angle: condition: 1m high above the ground,
Viewing angle: and texture of the obstacle is clear
Terrain sensor
Model: TR24S30
Power consumption: 5W
Operating frequency: 40Hz
Height measurement range*: 0.5-30m
Fixed height range: 1-30m
Viewing angle to ground: 35°
Service conditions: relative flight height of the aircraft
Service conditions: is higher than 1.5m and the speed
Service conditions: is less than 7m/s
Omnibearing radar (front, rear, left and right)
Model: OM24S30
Power consumption: 2W
Operating frequency: 40Hz
Quantity: standard configuration: front and rear
Quantity: obstacle avoidance (2)
Optional: omnibearing obstacle avoidance (4)
Obstacle sensing range: 2-30m (it varies with material,
Obstacle sensing range: position and shape of the
Obstacle sensing range: target object, etc.)
Service conditions: relative flight height of the aircraft
Service conditions: is higher than 1.5m and the speed
Service conditions: is less than 7m/s
*The effective use range of radar varies with material,
*position and shape of target obstacles, etc.
P30 multi-copter plant
protection aerial platform
Overall dimensions: 1,260×1,252×495mm
Overall dimensions: (when the propellers are folded)
1852×1828×495mm
Overall dimensions: (when t
he propellers are expanded)
Protection grade: IP67
Flight parameters
Empty weight: 22.8kg
Maximum effective take-off weight (MTOW): 38.5kg
（Sea level）
Maximum thrust-weight ratio: 2.05
Load ratio: 0.42
Hovering precision (good GNSS signal):
RTK enabled: ±10cm (horizontal),±10cm (vertical)
RTK not enabled: ±0.6m (horizontal),±0.3m (vertical) RTK
not enabled: (radar function enabled: 0.1m) Hovering
duration:
18min (18,000mAh, take-off weight 22kg)
10min (18,000mAh, take-off weight 38kg)
Power battery: B12620/B12800 smart battery is
Power battery: applicable
Maximum operating flight speed: 12m/s
Maximum flight speed: 12m/s
Maximum acceptable wind speed: 10m/s
Maximum flight altitude: 4,000m
Recommended operating temperature: -10
℃
to 40
℃
Specifications and parameters
Power system
Motor
Model: A16
Dimension (stator): 83×20mm
KV value: 100rpm/V
Rated power: 1,200W (single)
Maximum tension: 19.5kg (single)
Electronic speed controller
Model: VC12100
Maximum operating voltage: 52.2V (12SLipo)
Maximum continuous operating current: 100A
Foldable propeller
Material: nylon carbon fiber
Number of main copters: 4
Diameter: Φ920mm
