Freedom X Inverter Configuration
LCD Screen Icons
Icon Definition
AC MODE
Batt. MODE
Status LED Light Indicators
Indicator Definition
solid green
solid green
solid red
flashing
red
Appears in all modes. Indicates ~ 75–100% battery
capacity.
Appears in all modes. Indic
ates ~ 50–75% battery
capacity.
Appears in all modes. Indic
ates ~ 25–50% battery
capacity.
Appears in all modes. Indic
ates ~ 1–25% battery
capacity.
Appears in all modes. Indicates 0% battery capacity.
Appears in AC mode only and sometimes in Fault
mo
de. Indicates ~ 75–100% load capacity.
Appears in AC mode only and sometimes in Fault
mode.
Indicates ~ 50–75% load capacity.
Appears in AC mode only and sometimes in Fault
mode.
Indicates ~ 25–50% load capacity.
Appears in AC mode only and sometimes in Fault
mode. Indicates ~ 0–25% load capacity.
Indicates AC mode in which shore power is available
and passing through to the loads.
Indicates Battery mode (Inverte
r mode) in which the
inverter is running and supplying power to the loads
from the battery.
Indicates AC mode in which shore power is available
an
d passing through to the loads.
Indicates Battery mode (Inverte
r mode) in which the
inverter is running and supplying power to the loads
from the battery.
Indicates Fault mode and is accompanied by an error
co
de displayed on the LCD screen. For a list of error
codes, see “Warning Messages” on page 54.
Indicates a Warning condition and is accompanied by
a
n error code and a sounding alarm. For a list of error
codes, see “Warning Messages” on page 54.
