975-0767-01-01 51
Operating During Transition Between AC Mode and Battery Mode
Operating Limits
Power Output
The Freedom X can deliver up to 1200 watts of continuous utility
grade sine wave AC power. The wattage rating applies to resistive
loads such as incandescent lights.
Input Voltage
The allowable Freedom X input battery voltage ranges are shown in
the following table:
Operating
Condition
Battery
Vo
ltage Comment
Full Operating
Range
LBCO – 16.5
volts
Assuming the battery is full, the inverter will
operate until battery voltage goes past below
LBCO
a
a. To set LBCO, see “To change the Low Battery Cutout (LBCO) voltage:” on page 42.
and LBCO Shutdown delay timer
b
b. To set LBCO Shutdown Delay Timer, see “To change the LBCO Shutdown delay timer:”
on page 42.
.
Low Voltage
Ala
rm
< LBCO+0.5
volts
A silent low battery warning shows fault code
on the LCD screen.
Low Voltage
Sh
utdown
< LBCO The buzzer sounds a single one-second low
battery alarm beep and the LCD screen shows
fault code . After LBCO Shutdown delay
timer runs out, the unit shuts down inverter
output. The buzzer stops beeping and the LCD
screen shows fault code .
Instant Low
V
oltage
Shutdown
< 10.2 volts After two seconds below the
limit, the unit shuts
down inverter output completely. LCD screen
turns off completely.
High Voltage
Shutd
own
16.7 volts The buzzer sounds an over-voltage alarm beep
every second and the display shows fault code
alternating with the battery voltage.
The red status LED turns on.
NOTE: Although the Freedom X incorporates
over-voltage protection, it can still be damaged if
input voltage exceeds 16.7 volts.
Operating
Condition
Battery
Voltage Comment
Freedom X Owners Guide.book Page 51 Wednesday, May 11, 2016 10:32 AM
