Xantrex SW Series User Manual

TECHNICAL INFORMATION
Page
126
 2001 Xantrex Technology, Inc.
5916 - 195th Street N. E.
Arlington, WA 98223
Telephone: 360/435-8826
Fax: 360/435-2229
www.traceengineering.com
SW Series Inverter/Charger
Part No. 2031-5
Rev. C: February 2001
SETUP MENU – 48 VDC (120 VAC/60HZ) MODELS
To access the SETUP MENU, press the RED and GREEN buttons on your CONTROL PANEL (or
SWRC) at the same time. To exit the Setup Menu, press the ON/OFF MENU button or use the down
MENU HEADING button until you reach the USER MENU (menu headings 1 – 8)
.
MENU HEADING MENU ITEM
SELECTION
RANGE
DEFAULT
SETTINGS
USER
SETTINGS
Inverter Setup 9 Set Grid Usage FLT SELL SLT LBX FLT
Set Low Battery cut out VDC 32.0 – 70.0 44.0
Set LBCO delay minutes 00 - 255 15
Set Low battery cut in VDC 20.0 – 71.0 52.0
Set High battery cut out VDC 20.0 – 66.0 64.0
Set search watts 00 - 240 48
Set search spacing 20 – 255 59
Battery Charging 10 Set Bulk volts DC 40.0 – 64.0 57.6
Set Absorption time h:m 00:00 – 23:50 02:00
Set Float volts DC 40.0 – 64.0 53.6
Set Equalize volts DC 40.0 – 64.0 57.6
Set Equalize time h:m 00:00 – 23:50 02:00
Set Max Charge amps AC 01 - 35 30
Set Temp Comp LeadAcid Nicad LeadAcid
AC Inputs 11 Set Grid (AC1) amps AC 00 - 63 60
Set Gen (AC2) amps AC 00 - 63 30
Set Input lower limit VAC 80 - 111 108
Set Input upper limit VAC 128 - 149 132
Gen Auto Start Setup 12 Set Load Start amps AC 00 - 63 33
Set Load Start delay min 00.0 – 25.5 05.0
Set Load Stop delay min 00.0 – 25.5 05.0
Set 24 hr start volts DC 20.0 – 71.0 49.2
Set 2 hr start volts DC 20.0 – 71.0 47.2
Set 15 min start volts DC 20.0 – 71.0 45.2
Read LBCO 30 sec start VDC 20.0 – 71.0 44.0
Set Exercise period days 00 - 255 30
Set Maximum run time h:m 00:00 – 23:50 08:00
Gen Starting Details 13 Set RY7 Function GlowStop Run Run
Set Gen warmup seconds 16 - 255 60
Set Pre Crank seconds 00 - 255 10
Set Max Cranking seconds 00 - 15 10
Set Post Crank seconds 00 - 255 30
Auxiliary Relays R9 R10 14 Set Relay 9 volts DC 20.0 – 71.0 58.0
R9 Hysteresis volts DC 00.2 – 25.6 04.0
Set Relay 10 volts DC 20.0 – 71.0 59.0
R10 Hysteresis volts DC 00.2 – 25.6 04.0
Set Relay 11 volts DC 20.0 – 71.0 60.0
R1 Hysteresis volts DC 00.2 – 25.6 04.0
Bulk Charge Trigger Timer 15 Start Bulk Time H:M 00:00 – 23:50 00:00
Low Battery Transfer (LBX) 16 Set Low Battery transfer VDC 20.0 – 71.0 45.2
Set Low Battery cut in VDC 20.0 – 71.0 52.0
Battery Selling 17 Set Battery Sell volts DC 40.0 – 64.0 53.6
Set Max Sell amps AC 01 - 35 30
Grid Usage Timer 18 Set Start Charge time h:m 00:00 – 23:50 21:00
End Stop Charge time h:m 00:00 – 23:50 21:00
