I N S T A L L A T I O N A L T A L I N K
®
C 8 0 0 0 S E R I E S
Customer Expectation and Installation Guide 24
Installation Planning
Main Components
Xerox
®
C8000 is delivered with Print Engine, Scanner and Embedded Network Controller
Module Dimensions
Space Requirements / Service Space Envelope
The dimensions shown below provide the overall service space required, including the space to the nearest obstruction. The dimensions reflect both typical and
hallway installations and are absolute minimums.
Product Space Requirements
61.2” x 81.4”
1554 mm x 2067mm
Base Configuration + Integrated Finisher (Up to 35ppm only)
61.2” x 81.4”
1554 mm x 2067mm
Base Configuration + Office Finisher LX
(Booklet Maker)
78.2” x 81.4”
1986 mm x 2067 mm
Base Configuration + Business Ready Finisher
90.2” x 81.4”
2220 mm x 2067 mm
Base Configuration + Business Ready Booklet finisher
92.6” x 81.4”
2352 mm x 2067 mm
Base Configuration + Business Ready Booklet finisher + C/Z
folder
101.8” x 81.4”
2586 mm x 2067 mm
Base Configuration + Business Ready Booklet finisher + C/Z
folder +High Capacity Feeder
101.8” x 81.4”
2586 mm x 2067 mm
7. Device Direct (DD) Communications:
Each device will need to be communicating to Xerox through the internet via the Xerox Device Direct method for Remote Diagnostics
support. Follow the steps below (customer) to find how to setup Device Direct, if required.
Setting up Device Direct:
A) Go to the “Support and Drivers” link on Xerox.com.
Search for your product, then click on the Support link for that product.
In the search field, enter "Enroll Xerox Remote Services" and follow the instructions provided.
B) If the search does not return any instructions:
Click on the Documentation link for your product.
Open the System Administrators Guide and refer to the section of the guide which provides information Xerox Remote Services
Setup and follow the steps provided.
With Integrated Office Finisher (30/35ppm only)
With Office Finisher LX (Booklet Maker)
With Business Ready Finisher
With Business Ready Booklet Maker Finisher
Base configuration + Business Ready Booklet finisher + C/Z folder
Base configuration + Business Ready Booklet finisher + C/Z folder
+ High Capacity Feeder
