Xerox Phaser 3635MFP Voluntary Product Accessibility Template

www.xerox.com/Section508 6 of 10
Last Revision: 05/27/09
Section 1194.25 Self-Contained, Closed Products – Detail
Back to top
Criteria Supporting Features Remarks and explanations
(a) Self contained products
shall be usable by people
with disabilities without
requiring an end-user to
attach Assistive Technology
to the product. Personal
headsets for private
listening are not Assistive
Technology.
Some limitations exist Xerox Copier Assistant software not available for the product.
(b) When a timed response
is required, the user shall be
alerted and given sufficient
time to indicate more time
is required.
Supports
A time-out alert feature is present and controllable from a
menu selection.
(c) Where a product utilizes
touchscreens or contact-
sensitive controls, an input
method shall be provided
that complies with
§1194.23 (k) (1) through
(4).
Supports
The product uses a touch screen or contact-sensitive controls,
and an input method is provided that complies with
1194.23(k)(1) through (4).
(d) When biometric forms
of user identification or
control are used, an
alternative form of
identification or activation,
which does not require the
user to possess particular
biological characteristics,
shall also be provided.
Not applicable Biometric forms are not used.
(e) When products provide
auditory output, the audio
signal shall be provided at a
standard signal level
through an industry
standard connector that will
allow for private listening.
The product must provide
the ability to interrupt,
pause, and restart the audio
at anytime.
Supports There is no auditory output.
(f) When products deliver
voice output in a public
area, incremental volume
control shall be provided
with output amplification
up to a level of at least 65
dB. Where the ambient
noise level of the
environment is above 45
dB, a volume gain of at
least 20 dB above the
ambient level shall be user
selectable. A function shall
be provided to
Not applicable There is no voice output.

Xerox Phaser 3635MFP Specifications

General

Network ready	Yes
Dimensions (WxDxH)	472 x 478 x 54 mm
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Digital sender	No
Maximum duty cycle	75000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, Fax, FTP, USB
Maximum scan area	220 x 300 mm
Image formats supported	JPG, TIF
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	199
Paper input type	Paper tray
Total input capacity	550 sheets
Total output capacity	250 sheets
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	60 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Security algorithms	802.1x RADIUS, HTTPS
Supported network protocols (IPv4)	FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP, UDP
Internal memory	512 MB
Card reader integrated	-
Internal storage capacity	80 GB
Sound pressure level (printing)	59 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	15 W
Power consumption (PowerSave)	55 W
Power consumption (average operating)	600 W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	10 - 32 °C
Operating temperature (T-T)	16 - 30 °C
Storage relative humidity (H-H)	20 - 80 %
Operating relative humidity (H-H)	30 - 70 %
Sustainability certificates	ENERGY STAR
Certification	CE, FCC, RoHS
