Removal and Replacement Procedures 7 - 179
Key FRU Removal and
Replacement
This topic illustrates how to remove and replace key printer Field Replaceable Units
(FRUs). For more detailed removal/replacement procedures, refer to the Color Printer
Service & Support Resources CD-ROM. Procedures included here are:
■ Main board and its components 7 - 180
■ Power supply 7 - 183
■ Power control board 7 - 184
■ Upper feed roller asse 7 - 185
■ Preheat/drum heater a 7 - 187
■ Drum/transfix assemb 7 - 188
■ Drum-position sensor 7 - 192
■ Printhead 7 - 196
■ X-axis motor and driv 7 - 199
■ Y-axis belt drive assem 7 - 200
■ Cap/wipe/purge assem 7 - 202
This topic concludes with n about printhead locking.
