In both figures below, the left image shows an ideal state, the middle
image shows a rising stitch problem, and the third image shows a
falling stitch problem.
The stitch alignment should only be required if the scanner has been
moved or if there is a visual problem with broken lines in the images
as seen below. When broken lines occur, normalization is needed to
correct the problem.
Figure 1: Horizontal Stitch
The broken lines can also be seen on a vertical image as well. This is
shown in the following graphic.
Figure 2: Vertical Stitch
