Parts Lists
Phaser 3320 and WorkCentre 3315/3325 Xerox Internal Use Only
Service Manual
5-20
30 LVPS Fan (110V printers only) 127N07782
31 Exhaust Fan
32 Sensor Harness
33 Clutch Motor Harness
34 Air Temp Harness
35 Exit Harness
36 Rear Cover & Bin Full Sensor Harness
37 HVPS Harness
38 LVPS (Signal) Harness
39 Flat Cable
40 Therm Fuser Harness
41 Power LVPS Harness
42 Inlet-2 AC Harness
43 Bias Fuser Harness
44 HVPS 105N02248
45 Electric Clutch (Registration Clutch) 121N01219
46 Electric Clutch (Pick Up Clutch) 121N01220
47 TR(KOR) ETC Spring
48 4 Bush
49 Idle Feed M Bush
50 L TR M Bush
51 SAW P Plate
52 Bushing Push P Plate
53 4PI Ring M E Fixer
54 Swing Collar
55 Swing Bracket
56 Regi
57 Transfer Earth Plate
58 TR L Bush
59 Path EX Duplex Frame
60 Exit Shaft Bush
61 Base Frame
62 Ground Paper Bracket
63 LSU Bracket
64 Duplex Frame Guide
65 Exit Sensor and Holder (not part of Fuser) 130N01669
Item Name Part Number
www MK-Electronic de

Xerox WorkCentre 3315 Specifications

General

Print Technology	Laser
Duplex Printing	Manual
Functions	Print, Copy, Scan, Fax
First Page Out Time	As fast as 6.5 seconds
Copy Resolution	Up to 600 x 600 dpi
First Copy Out Time	As fast as 10 seconds
Fax Speed	33.6 Kbps
Print Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Paper Sizes	Letter, Legal, A4, A5, Executive
Scan Resolution	Up to 4800 x 4800 dpi
Weight	25.1 lbs
Operating System Compatibility	Windows, Mac, Linux
