Xerox WorkCentre 3315 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-21
66 TR Holder
67 Bottom Frame Plate
68 TR Guide
69 RIB TR Guide
70 ML80 Foot
71 Deve Guide ETC Spring
72 TR ETC Spring
73 LVPS Insulation
74 Guide TR Ground
75 Paper BRKT Ground
76 Gear BRKT Ground
77 HVPS Ground
78 LSU Bracket Ground
79 Bottom L Plate Ground
80 SCF Ground
81 Varistor Ground
82 Controller Shield
83 LVPS L Shield
84 Path Duplex Sheet
85 TR Terminal
86 PR Fuser Terminal
87 Idle Feed Shaft
88 P One Way Clutch
89 SCF M Idle Roller
90 28 DR Duplex Gear
91 23/23 RDCN Gear 007N01706
92 DUP Roller Shaft
93 Empty Actuator 120N00552
94 Regi Actuator
95 Feed Actuator
96 Holder L OPC Lever
97 Holder R OPC Lever
98 Bar Coupling Lever 005N01146
99 96 Idle Exit Gear 007N01707
100 65 Exit Gear
101 29 Idle Feed Gear 007N01708
Item Name Part Number
93
Empty Actuator
www MK-Electronic de

Xerox WorkCentre 3315 Specifications

General

Print Technology	Laser
Duplex Printing	Manual
Functions	Print, Copy, Scan, Fax
First Page Out Time	As fast as 6.5 seconds
Copy Resolution	Up to 600 x 600 dpi
First Copy Out Time	As fast as 10 seconds
Fax Speed	33.6 Kbps
Print Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Paper Sizes	Letter, Legal, A4, A5, Executive
Scan Resolution	Up to 4800 x 4800 dpi
Weight	25.1 lbs
Operating System Compatibility	Windows, Mac, Linux
