Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-13
PL 1.4 WorkCentre 3315/3325 Covers
Item Name Part Number
1 Rear Door Assembly (Rear Door)
1-1 Rear Cover 095N00415
1-2 Change Dup Guide
1-3 Idle Roller
1-4 Dup Change Guide Sponge
2 Middle Cover 095N00413
3 Right Cover Assembly (Right Cover)
3-1 Right Cover 095N00417
3-2 DIMM Cover
3-3 Sheet-Output_5V
Note: Order this adhesive-backed sheet to cover the 5V
i
nput when replacing the Right Cover.
019N01079
4 Left Cover Assembly (Left Cover)
4-1 Left Cover 095N00418
4-2 Left Dummy Cover
4-3 Handset Dummy Cover
5 Front Cover
5-1 Front Cover 095N00419
5-2 Cover MP Link
5-3 Front Locker
5-4 CS Spring
5-5 Taptype Screw
5-6 Tray MP Guide
5-7 Exit Guide
To Next Page
