Xerox WorkCentre 3325 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-19
Parts List 3.1 Frame
Item Name Part Number
0 Main Frame
1 Taptype Screw
2 Taptype Screw
3 Taptype Screw
4 Clutch and Sensor MP Harness
5 Phaser 3320/WorkCentre 3315
LVPS (110V)
LVPS (220V)
105N02245
105N02246
WorkCentre 3325
LVPS (110V)
LVPS (220V)
105N02247
105N02249
6 Electric Clutch (Bypass Tray Clutch) 121N01219
7 Clutch Spacer
8 Regi Feed Shaft
9 MP (Bypass Tray) 130N01676
10 Fuser (110V), shown in Parts List 3.3 Fuser
Fuser (220V), shown in Parts List 3.3 Fuser
126N00410
1
26N00411
11 Drive 007N01711
12 Feed Drive 022N02679
13 Rear Frame
14 ETC Frame
15 Graphite Grease
16 Bearing Grease
17 Bearing Grease
18 Registration Sensor and Feed Sensor 130N01574
19 Thermistor NTC Assy, shown in Parts List 3.3 Fuser 130N01668
2
0 Taptype Screw
21 Taptype Screw
22 Taptype Screw
23 Taptype Screw
24 CS Ring
25 TS Spring 009N01653
26 CS Spring
27 TS Spring
28 Cable Clamp
29 Cable Clamp
18
Registration
Sensor
and Feed Sensor
and Feed Sensor
