Xerox WorkCentre 3325

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-27
Parts List 3.3 Fuser
Item Name Part Number
0 110V Fuser
220V Fuser
126N00410
126N00411
2 NTC Assy Thermistor 130N01668
3 Thermostat
4 Halogen Lamp (110V/220V)
5 Taptype Screw
6 Taptype Screw
7 Taptype Screw
8 E Ring
9 E Ring
10 ETC Spring
11 CS Spring
12 CS Spring
13 ETC Spring
14 ETC Spring
15 Ball Bearing
16 Joint Fuser Harness
17 Con Fuser Harness
18 PR 1st Bush
19 Claw Guide
20 Ground PR Guide
21 Jam Holder
22 Fuser Frame
23 HR Bush
24 2nd PR Bush
25 Input Guide
26 Bearing Bracket
27 Gear Bracket
28 PR M Ground
29 Fuser Cover
30 Idle Roller
31 Pressure Roller
32 2nd Pressure Roller
33 Fuser Gear
34 Exit Idle Gear
35 L Jam Link Lever
36 R Jam Link Lever
37 Exit Idle Roller
38 Heat Roller
39 L Lamp Cap
40 R Lamp Cap
41 Caution Label
42 F/UP Idle Shaft IEX
