Xerox WorkCentre 3325

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-31
Parts List 3.5 Drive
Item Name Part Number
0 Drive
1 Taptype Screw
2 BLDC Motor (Main Drive Motor) 127N07780
3 Plain Washer
4 Motor Bracket
5 95-81 Exit Gear
6 65-28 Feed Gear
7 29 DR Fuser Gear
8 Clutch Hub Gear
9 79 IN DR Fuser Gear
10 69 IN DR OPC Gear
11 Clutch Hub
12 TS Spring
13 53 Out DR OPC Gear
14 59 Idle Gear
15 73 Idle Gear
16 Cam Coupler
17 Coupler
18 CS Spring
19 73 Coupler Gear
20 Gear Bracket
21 Bearing Grease
22 Bearing Grease
