Xerox WorkCentre 3325

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-39
PL 6.1 WorkCentre 3315/3325 Main
Item Name Part Number
0 WorkCentre 3315, 4 in 1 ADF See Parts List 7.1 WorkCentre
3315 ADF (1/2)
0 WorkCentre 3325DN 4 in 1 DADF See Parts List 8.1 WorkCentre
3325 DADF Platen
0 WorkCentre 3325DNI 4 in 1 DADF See Parts List 8.1 WorkCentre
3
325 DADF Platen
1 Cover
2 Frame Main
3 ADF/DADF
4 DIMM (3325-only Option) Sales order only
5 Cassette 050N00650
6 Phaser 3320, Main Board See
PL 1.0
WorkCentre 3315, Main Board 140N636xx (see note)
WorkCentre 3325DNI, Main Board 140N636xx (see note)
7 PBA SUB-Modem (Fax Board) 140N63646
8 Modem Cable (Modem Interface Cable) 117N01937
9 Cover-H Fax Board
10 Optional Hard Drive 007N01809
11 Fuser (110V)
Fuser (220V)
126N00410
126N00411
12 Frame-Rear
13 Print Cartridge See Consumables and
M
aintenance Items
Phaser 3320, Main Board
See
PL 1.0
(see note)
WorkCentre 3315, Main Board
xx (see note)
WorkCentre 3325DNI, Main Board
