Xerox WorkCentre 3325 User Manual

Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-41
Parts List 7.1 ADF (1/2)
Item Name Part Number
0 ADF (Cushion not included. See PL 9.1, item 1.5) 022N02680
1 ADF Top Cover
1.1 Cover ADF CSP
1.2 Pick Up Module
1.2.1 Pick Up Housing CSP (with 1,2,7) 130N01672
1.2.2 Chess Ring CSP
1.2.4 Gear Drive Pick CSP
1.2.5 Idle Gear Pick CSP
1.2.6 Gear Separate Roller CSP 130N01673
1.3 Idle Roller Module
1.3.1 Roller Idle CSP
1.3.4 Frame Idle Unit CSP
1.4 Stopper Paper CSP
2 ADF Base Frame See
page 5-43
2.1 Cover Platen CSP S
ee page 5-43
2.2 Stopper Output CSP See page 5-43
2.3 Slide Stopper CSP See page 5-43
3 Paper Path Assembly S
ee page 5-43
4 ADF Motor 127N07781
5 Input Tray
5.2 Pinion Gear CSP
5.4 Stacker CSP
5.5 Rear Edge Guide CSP
5.6 Front Edge Guide CSP
6 Rear ADF Cover CSP
7 Front ADF Cover CSP
www MK-Electronic de
