Parts Lists
Xerox Internal Use Only Phaser 3320 and WorkCentre 3315/3325
Service Manual
5-45
Parts List 8.1 WorkCentre 3325 DADF Platen
Item Name Part Number
0 DADF 022N02682
2 Platen DADF
3 Lower DADF
4 Upper DADF
5 DADF Drive 007N01712
6 GND1 CBF Harness
7 Zener GND CBF Harness
8 DADF PBA (DADF Board) 140N63301
9 DADF Harness
10 DADF Rear Cover
11 DADF Front Cover
12 DADF Open Cover 002N03064
12.2 DADF Up Pick MEA Unit (Sep Pad see PL#8.3) 130N01533
12.3 Bush PMO
12.4 Taptype Screw
12.5 Stopper MEA Unit
12.6 Open Cover
12.7 Sensor M DOC Guide
12.8 Pick Up Spring ETC
12.9 Upper DADF Damper
13 DADF Stacker
14 DADF Hinge MEA Unit 003N01083
15 Hinge Unit MEA 003N01051
16 Taptype Screw
17 Machine Screw
To Next Page
